Powerful Curved LiPo Battery 225mAh 3.7V Lithium Polymer Rechargeable Battery

Certification
China AllrunBattery certification
China AllrunBattery certification
I'm Online Chat Now

Powerful Curved LiPo Battery 225mAh 3.7V Lithium Polymer Rechargeable Battery

Powerful Curved LiPo Battery 225mAh 3.7V Lithium Polymer Rechargeable Battery
Powerful Curved LiPo Battery 225mAh 3.7V Lithium Polymer Rechargeable Battery Powerful Curved LiPo Battery 225mAh 3.7V Lithium Polymer Rechargeable Battery

Large Image :  Powerful Curved LiPo Battery 225mAh 3.7V Lithium Polymer Rechargeable Battery

Product Details:
Brand Name: AllrunBattery
Model Number: 401740
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Factory standard package, or on demand.
Delivery Time: 5~8 working days when cells in stocks.
Payment Terms: T/T, PayPal, Western Union.
Supply Ability: 40 million pieces LiPo battery cells per year.

Powerful Curved LiPo Battery 225mAh 3.7V Lithium Polymer Rechargeable Battery

Description
Name: Rechargeable Curved Battery Cell Size: 4.0*17*40mm(T*W*L)
Voltage: 3.7V Capacity: 225mAh
Continous Discharge Current: 225mA Weight: 10g
High Light:

Powerful Curved LiPo Battery

,

Curved LiPo Battery 225mAh

,

3.7V Lithium Polymer Rechargeable Battery

Allrun 3.7V 225mAh 401740 Curved Lithium Polymer Battery



Welcome to Allrun curved LiPo battery section, they are greatly suited to wearable products and IoT smart devices. With Allrun customized shape li-polymer batteries, all the internal space can be utilized for more energy.

Key Features:

  • High Reliability
  • Powerful and Light-weight
  • Low Self-discharge
  • High Energy Density
  • Wide operating temperature: -20 ℃~60 ℃
  • The battery offers high cycle stability with 500 charge/discharge cycles and 80% residual capacity.





Datasheet



Item

Allrun 3.7V 225mAh 401740 Curved Lithium Polymer Battery

Battery Type

Lithium-ion Polymer Battery

Capacity

225mAh

Normal Voltage

3.7V

Thickness

4.0 mm MAX

Width

17.0 mm MAX

Length

40.0 mm MAX

Charge Cut-off Voltage

4.2V

Discharge Cut-off Voltage

3.0V

Standard Charge Current

112.5mA (0.5C)

Max Charge Current

450mA (2C)

Standard Discharge Current

112.5mA (0.5C)

Max Discharge Current

225mA (1C)

Pulse Discharge Current

450mA (2C) for 2 seconds

PCM

YES

Wire Cable and Connector

TBD



Applications



Powerful Curved LiPo Battery 225mAh 3.7V Lithium Polymer Rechargeable Battery 0

More and more wearable devices nowadays use AllrunBattery's novel curved batteries, such as smart clothing, AR/VR, Bluetooth headsets, wristbands, and smartwatches. With this, consumer electronics devices are able to take advantage of their internal space, increasing their capacity and functionality. Providing the most reliable possible battery solution requires close cooperation with our R&D team.





Curved LiPo Battery Safety Notes

  1. Avoid using lead-acid, NiCd, or NiMH chargers.
  2. Be careful not to abuse these batteries, such as shorting, bending, crushing, or puncturing them.
  3. Charge and use should never be left unattended.
  4. Always inspect batteries and surrounding circuitry constantly for any damage, loose wiring, or the possibility of short circuits.
  5. Do not use or leave the battery at very high-temperature conditions(for example, strong direct sunlight or a vehicle in extremely hot conditions). Otherwise, it can overheat or fire, or its performance will degenerate and its service life will be decreased.
