0.4mm Power Ultra Thin LiPo Battery 3.7V 8mAh For Electronic Sensors

Certification
China AllrunBattery certification
China AllrunBattery certification
I'm Online Chat Now

0.4mm Power Ultra Thin LiPo Battery 3.7V 8mAh For Electronic Sensors

0.4mm Power Ultra Thin LiPo Battery 3.7V 8mAh For Electronic Sensors
0.4mm Power Ultra Thin LiPo Battery 3.7V 8mAh For Electronic Sensors

Large Image :  0.4mm Power Ultra Thin LiPo Battery 3.7V 8mAh For Electronic Sensors

Product Details:
Brand Name: AllrunBattery
Model Number: 042040
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Factory standard package, or on demand.
Delivery Time: 5~8 working days when cells in stocks.
Payment Terms: T/T, PayPal, Western Union.
Supply Ability: 40 million pieces LiPo battery cells per year.

0.4mm Power Ultra Thin LiPo Battery 3.7V 8mAh For Electronic Sensors

Description
Name: Ultra Thin LiPo Battery Cell Size: 0.4*20*40mm(T*W*L)
Voltage: 3.7V Capacity: 8mAh
Standard Discharge Current: 4mA (0.5C) Weight: 0.3g
High Light:

Power Ultra Thin LiPo Battery

,

0.4mm Ultra Thin LiPo Battery

,

Power LiPo Battery 8mAh

3.7V 8mAh 0.4mm Ultra Thin LiPo Battery For Electronic Sensors



Welcome to Allrun ultra-thin lipo battery section, they are greatly suitable for a variety of applications, such as MP3 players, RFID electronic tags, smart cards, second-generation bank cards, Smart knee pads, etc. With Allrun customized slim li-polymer batteries, all the internal space can be utilized for more energy.



Description

Allrun special-shaped batteries are available in a range of thicknesses from 0.35mm to 7mm. This ultra-thin battery provides long cycle life with low self-consumption and can always be as thin as paper.

Here are the services we offer:

  1. Customized and flexible power solutions according to your requirements

  2. An efficient and reliable performance

  3. Support OEM and ODM

  4. Different sizes and models can be designed and manufactured



Datasheet



Item 3.7V 8mAh 0.4mm Ultra Thin LiPo Battery For Electronic Sensors
Battery Type Rechargeable Lithium Polymer Battery
Capacity 8mAh
Normal Voltage 3.7V
Thickness 0.4mm MAX
Width 20.0mm MAX
Length 40.0mm MAX
Charge Cut-off Voltage 4.2V
Discharge Cut-off Voltage 3.0V
Standard Charge Current 4mA (0.5C)
Max Charge Current 16mA (2C)
Standard Discharge Current 4mA (0.5C)
Max Discharge Current 8mA (1C)
Pulse Discharge Current 16mA (2C) for 2 seconds
PCM TBD
Wire Cable and Connector TBD







 Safety Notes of Ultra-thin LiPo Battery

  1. Avoid using lead-acid, NiCd, or NiMH chargers.
  2. Be careful not to abuse these batteries, such as shorting, bending, crushing, or puncturing them.
  3. Charge and use should never be left unattended.
  4. Always inspect batteries and surrounding circuitry constantly for any damage, loose wiring, or the possibility of short circuits.
  5. Do not use or leave the battery at very high-temperature conditions(for example, strong direct sunlight or a vehicle in extremely hot conditions). Otherwise, it can overheat or fire, or its performance will degenerate and its service life will be decreased.
