9048155 75C 22.2V 6S 5200mAh High Discharge LiPo Battery Pack

Certification
China AllrunBattery certification
China AllrunBattery certification
I'm Online Chat Now

9048155 75C 22.2V 6S 5200mAh High Discharge LiPo Battery Pack

9048155 75C 22.2V 6S 5200mAh High Discharge LiPo Battery Pack
9048155 75C 22.2V 6S 5200mAh High Discharge LiPo Battery Pack 9048155 75C 22.2V 6S 5200mAh High Discharge LiPo Battery Pack 9048155 75C 22.2V 6S 5200mAh High Discharge LiPo Battery Pack

Large Image :  9048155 75C 22.2V 6S 5200mAh High Discharge LiPo Battery Pack

Product Details:
Brand Name: AllrunBattery
Model Number: 9048155
Payment & Shipping Terms:
Minimum Order Quantity: MOQ: 100PCS
Price: Negotiable
Packaging Details: Factory standard package, or on demand.
Delivery Time: 5~8 working days when cells in stocks.
Payment Terms: T/T, PayPal, Western Union.
Supply Ability: 40 million pieces LiPo battery cells per year.

9048155 75C 22.2V 6S 5200mAh High Discharge LiPo Battery Pack

Description
Battery Type: High Discharge LiPo Battery Voltage: 22.2V
Capacity: 5200mAh Pack Size: 54*48*155mm(T*W*L)
Continuous Discharge C-rate: 75C Max Continuouswork Current: 390A
High Light:

75C High Discharge LiPo Battery

,

22.2V High Discharge LiPo Battery

,

6S 5200mAh LiPo Battery

Allrun 75C 5200mAh 6S 22.2V High Discharge LiPo Battery Pack



Welcome to Allrun high discharge(C-rate) lipo battery section, they are widely used in various fields, such as model aircraft ( RC ), medical equipment, drones for aerial and agricultural plant protection purposes, emergency power supplies, power tools, and so on.



The high rate discharge lithium polymer battery represents the charge and discharge capacity of lithium polymer batteries relative to the standard rate discharge lithium polymer battery. A lithium-polymer battery is normally measured using a "C" value to represent its charge and discharge current ratio. Batteries with a C-rate number higher than 1 are considered high-rate batteries. The larger the C-rate number of a li-polymer battery, the higher the rate of the li-polymer battery.





Datasheet



Item

Allrun 75C 5200mAh 6S 22.2V High Discharge LiPo Battery Pack

Battery Type Rechargeable LiPo Battery
Capacity 5200mAh
Normal Voltage 22.2V
Thickness 54mm MAX
Width 48mm MAX
Length 155mm MAX
Charge Cut-off Voltage 25.2V
Discharge Cut-off Voltage 18.0V
Standard Charge Current 2600mA (0.5C)
Max Charge Current 5200mA (1C)
Max Continuous Discharge Current 390A (75C)
Pulse Discharge Current 780A (for 2 seconds)
Connector TBD





 Safety Notes of High C-rate LiPo Battery

  1. Avoid using lead-acid, NiCd, or NiMH chargers.
  2. Be careful not to abuse these batteries, such as shorting, bending, crushing, or puncturing them.
  3. Charge and use should never be left unattended.
  4. Always inspect batteries and surrounding circuitry constantly for any damage, loose wiring, or the possibility of short circuits.
  5. Do not use or leave the battery at very high-temperature conditions(for example, strong direct sunlight or a vehicle in extremely hot conditions). Otherwise, it can overheat or fire, or its performance will degenerate and its service life will be decreased.
